MEXICO SOLAR WATER HEATER

  Key Points:
♦ Model : CSR-24
♦ Vacuum tubes : 58-1800mm,(red tube),24 tubes,
♦ Tank Capacity : 206L
♦ System capacity:278L (206L+72L)
♦ Absorb er area: 3.192M2
♦ Water tank size(inner/outer dia.) : 470/360mm
♦ Insulation : 55mm high density polyurethane
♦ Bracket : 1.2mm SUS-201 stainless steel
♦ Bolts and nuts:SUS304-2B
