Mini Portable Baby 60L Non Pressure Solar Water Heater

KEY POINTS:
Systsem volume:60L
Vauum tubes:58*1000MM
Water tank diameters:360/460mm
Insulation layer thickness: 50mm
Bracket: Stronger Galvanized steel
System angle: 45 degree
System absorber area: 0.44MM
Warranty: 5 years.
MOQ: 10 SETS

  • Specifications

  • Diagram

  • Download







Features:



Cheap and reliable solution, Simple structure, Easy installation
High efficiency
Withdraws water by gravity, working pressure no more than 0.1MPa
Operates without any power supply
Optional Electric heater can be applied, 1500W,2000W or 3000W
Hot water can be used directly, or can be used as a pre-heat.



Material:



  1. Inner tank:0.4mm thickness SUS304 stainless steel
  2. Vacuum tube: QB-AL-N/AL-47-1500/58-1800
  3. Outer tank:0.4mm thickness painted steel or PDVF
  4. Frame:1.5mm thickness coated galvanized steel
  5. The material of insulation: 55mm thicknesspolyurethane foam
  6. Tube coating: Cu-AL-N-AL
  7. The reflector: aluminum alloy plate/stainless steel (optional)



Non Pressure Series:



Non-pressurized solar water heater is a kind of solar water heating system that solar collector and storage water tank are connected together, water tank on the top and collector panel on the bottom. It relies on the natural circulation of waters between the collector and the water tank. As water in the vacuum tubes is heated, it rises naturally into the tank, while cool water in the tank flows down to the bottom of the vacuum tubes, causing circulation throughout the system. It is a simple and safe solution to get heat power from the sun.
